Year | 1919 |
Weapon Type | Light Field Howitzer |
Origin & Designer | Germany/Krupp |
Numbers Produced | 220 |
Crew | 7 |
Calibre | 105mm (105x155R) |
Elevation | -10° to +40° |
Traverse | 4° |
Breech | Horizontal Sliding Breech |
Recoil | Hydrospring |
Gun Sight | [@gun_sight] |
Gun Mount | [@gun_mounts] |
Carriage | Box Trail |
Trailers | [@trailers] |
Gun Shield | 4mm |
Armoured Plate | [@armoured_plate] |
Barrel Length | 2.310mm (L/22) |
Overall Length | [@length] |
Width | [@width] |
Height | 1.77m |
Weight | Weight in Traction: 2.300 kg Weight in Action: 1.525 kg
|
Round Weight | 15.71 kg |
Muzzle Velocity | 427 m/s |
Feed | [@feed] |
Magazine Capacity | [@magazine_capacity] |
Practical Rate of Fire | [@practical_rate_of_fire] |
Rate of Fire | 5 r.p.m. |
Maximum Rate of Fire | [@maximum_rate_of_fire] |
Maximum Ceiling | [@maximum_ceiling] |
Maximum Ground Range | [@maximum_ground_range] |
Maximum Range | 9.700m |
Armour Penetration | [@armour_penetration] |
Traction | Horse Drawn (Six Horses) or Motorised |
Variants | Standard Regimental Field Howitzer of the Infantry Divisions. |
Notes | The Obusier de 105 GP was originally a First World War German howitzer designed by Krupp. After the armistice, many of these weapons were handed over to the Belgian army in the way of war reparations and became their standard field howitzer. These were issued to artillery regiments located in infantry divisions. |
