Year | 1943 |
Weapon Type | Medium Anti-Tank Gun |
Origin & Designer | France-Germany/Rheinmetall-Puteaux |
Numbers Produced | 46 |
Crew | 5 |
Calibre | 75mm (75x350R) |
Elevation | -8° to +25° |
Traverse | 60° |
Breech | Vertical Sliding Block |
Recoil | Hydropneumatic |
Gun Sight | Telescopic |
Gun Mount | [@gun_mounts] |
Carriage | Split Trail |
Trailers | [@trailers] |
Gun Shield | Two 4mm Plates |
Armoured Plate | [@armoured_plate] |
Barrel Length | 2.270mm (L/36) |
Overall Length | 4.68m |
Width | 1.85m |
Height | 1.05m |
Weight | Weight in Traction: 1.270 kg Weight in Action: 1.190 kg |
Round Weight | AP: 6.4 kg HE: 6.8 kg |
Muzzle Velocity | AP: 570 m/s HE: 450 m/s |
Feed | [@feed] |
Magazine Capacity | [@magazine_capacity] |
Practical Rate of Fire | [@practical_rate_of_fire] |
Rate of Fire | 14 r.p.m. |
Maximum Rate of Fire | [@maximum_rate_of_fire] |
Maximum Ceiling | [@maximum_ceiling] |
Maximum Ground Range | [@maximum_ground_range] |
Maximum Range | 10.000m |
Armour Penetration | 80mm @ 500m @ 70° |
Traction | Motorised (Truck) |
Variants | [@variants] |
Notes | [@notes] |
