Year | 1943 |
Weapon Type | Medium Anti-Tank Gun |
Origin & Designer | Germany/Rheinmetall |
Numbers Produced | 210 |
Crew | 8 |
Calibre | 75mm (75x714R) |
Elevation | -5° to +22° |
Traverse | 65° |
Breech | Semi-Automatic Horizontal Sliding Block |
Recoil | Hydropneumatic |
Gun Sight | Telescopic |
Gun Mount | [@gun_mounts] |
Carriage | Split Trail |
Trailers | [@trailers] |
Gun Shield | 8mm |
Armoured Plate | [@armoured_plate] |
Barrel Length | 3.450mm (L/48) |
Overall Length | 6.18m |
Width | 2.0m |
Height | 1.25m |
Weight | Weight in Traction: 1.500 kg Weight in Action: 1.425 kg |
Round Weight | AP: 4.1 kg HE: 5.8 kg |
Muzzle Velocity | AP: 990 m/s HE: 548 m/s |
Feed | [@feed] |
Magazine Capacity | [@magazine_capacity] |
Practical Rate of Fire | [@practical_rate_of_fire] |
Rate of Fire | 12 r.p.m. |
Maximum Rate of Fire | [@maximum_rate_of_fire] |
Maximum Ceiling | [@maximum_ceiling] |
Maximum Ground Range | [@maximum_ground_range] |
Maximum Range | 10.000 |
Armour Penetration | 120mm @ 500m @ 30° |
Traction | Motorised (Heavy Truck) |
Variants | [@variants] |
Notes | [@notes] |
