Year | February to March 1937 |
Vehicle Type | Light Tank |
Origin & Designer | Germany/MAN & Daimler-Benz |
Numbers Produced | 25 |
Crew | 3 (Commander/Gunner, Loader/Radio Operator & Driver) |
Main Armament | 1 x 20mm L/55 KwK 30 Gun |
Main Armament | [@sponson_traverse] |
Elevation | -9.5 ° to +20° |
Turret Traverse | 360° (Manual) |
Gun Traverse | [@gun_traverse] |
Gun Mount | [@gun_mounts] |
Maximum Range | [@maximum_range] |
Armour Penetration | [@armour_penetration] |
Gun Sight | TZF-4 (2.5x) |
Secondary Armament | 1 x 7.92mm MG34 |
Smoke Discharger | [@smoke_discharger] |
Ammunition Carried | 180 x 20mm + 2.250 x 7.92mm |
Height | 1.96m |
Width | 2.14m |
Length | 4.76m |
Combat Weight | 7.900 kg |
Ground Clearance | 0.29m |
Fording Depth | 0.85m |
Trench Crossing | 1.71m |
Obstacle Clearance | 0.42m |
Climbing Ability | 30° |
Radio | FuG-5 |
Armour | Hull Front: 13mm Hull Sides: 13mm Hull Rear: 13mm Hull Top: 12mm Hull Bottom: 5mm Gun Mantle: 15mm Turret Front: 13mm Turret Sides: 13mm Turret Rear: 13mm Turret Top: 10mm |
Engine | Maybach HL 62TR |
Transmission | 6 Forward & 1 Reverse |
Maximum Road Range | 190 km |
Maximum Cross Country Range | 126 km |
Maximum Water Range | [@maximum_water_range] |
Maximum Road Speed | 40 kph |
Maximum Cross Country Speed | 40 kph |
Maximum Water Speed | [@maximum_water_speed] |
Variants | [@variants] |
Notes | Ausf B was built with all the previous errors found on the Ausf a/1 a/2 and a/3 being modified. These included drive sprockets, return rollers, wider road wheels and transmission. Further modifications were made to the engine with improved ventilation and cooling systems and exhaust. |
