| Year | March 1941 |
| Vehicle Type | Light Reconnaissance Tank |
| Origin & Designer | Germany/FAMO |
| Numbers Produced | 524 |
| Crew | 3 (Commander/Gunner, Loader/Radio Operator & Driver) |
| Main Armament | 1 x 20mm L/55 KwK 30 Gun |
| Main Armament | [@sponson_traverse] |
| Elevation | -9.5° to +20° |
| Turret Traverse | 360° (Manual) |
| Gun Traverse | [@gun_traverse] |
| Gun Mount | [@gun_mounts] |
| Maximum Range | [@maximum_range] |
| Armour Penetration | [@armour_penetration] |
| Gun Sight | TZF-4 |
| Secondary Armament | 1 x 7.92mm MG34 |
| Smoke Discharger | [@smoke_discharger] |
| Ammunition Carried | 180 x 20mm + 2.700 x 7.92mm |
| Height | 2.15m |
| Width | 2.28m |
| Length | 4.81m |
| Combat Weight | 9.500 kg |
| Ground Clearance | 0.34m |
| Fording Depth | 0.92m |
| Trench Crossing | 1.70m |
| Obstacle Clearance | 0.42m |
| Climbing Ability | 30° |
| Radio | FuG-5 |
| Armour | Hull Front: 35mm Hull Sides: 15mm Hull Rear: 15mm Hull Top: 15mm Hull Bottom: 5mm Gun Mantle: 30mm Turret Front: 30mm Turret Sides: 15mm Turret Rear: 15mm Turret Top: 10mm |
| Engine | Maybach HL 62TR |
| Transmission | 6 Forward & 1 Reverse |
| Maximum Road Range | 200 km |
| Maximum Cross Country Range | 100 km |
| Maximum Water Range | [@maximum_water_range] |
| Maximum Road Speed | 40 kph |
| Maximum Cross Country Speed | 19 kph |
| Maximum Water Speed | [@maximum_water_speed] |
| Variants | [@variants] |
| Notes | The Ausf F was the last Pz Mk. II to be built in large numbers. It had the same basic armament as previous models but thicker frontal armour. The hull front was changed from rounded to a flat design and extra armour added to the gun mantlet, was increased to 30mm. Other modifications included new cupola and suspension. |
