PANZERBEFEHLSWAGEN AUSF H (Sd.Kfz 266, 267 & 268)

PANZERBEFEHLSWAGEN AUSF H (Sd.Kfz 266, 267 & 268)
Image: Panzerbefehlswagen Ausf H
YearNovember 1940
Vehicle TypeMedium Command Tank
Origin & DesignerGermany/Daimler-Benz
Numbers Produced145
Crew5 (Commander, Staff Officer, 2 x Radio Operators & Driver)
Main Armament1 x 7.92mm MG34 (Turret)
Main Armament[@sponson_traverse]
Elevation-10° to +35°
Turret Traverse[@turret_traverse]
Gun Traverse60°
Gun Mount[@gun_mounts]
Maximum Range[@maximum_range]
Armour Penetration[@armour_penetration]
Gun SightKgZF2
Secondary Armament[@secondary_armament]
Smoke Discharger[@smoke_discharger]
Ammunition Carried2.550 x 7.92mm
Height2.44m
Width2.95m
Length5.40m
Combat Weight21.800 kg
Ground Clearance0.38m
Fording Depth0.80m
Trench Crossing2.30m
Obstacle Clearance0.60m
Climbing Ability30°
RadioSd.Kfz 266: FuG-6 & FuG-2
Sd.Kfz 267: FuG-6 & FuG-8
ArmourHull Front: 60mm
Hull Sides: 30mm
Hull Rear: 30mm
Hull Top: 16mm
Hull Bottom: 16mm
Gun Mantle: 30mm
Turret Front: 30mm
Turret Sides: 30mm
Turret Rear: 30mm
Turret Top: 10mm
EngineMaybach HL 120TRM (Petrol)
Transmission6 Forward &1 Reverse
Maximum Road Range165 km
Maximum Cross Country Range95 km
Maximum Water Range[@maximum_water_range]
Maximum Road Speed40 kph
Maximum Cross Country Speed18 kph
Maximum Water Speed[@maximum_water_speed]
Variants[@variants]
NotesThe Pz.Bef.Wg III Ausf E was the third model in the series of command tanks based on the Panzer III. The differences were that turret was bolted into place, a frame antenna was added and the dummy gun could now resemble either a 37mm KwK 36 or 50mm KwK 38 depending on the model. Other changes were made with the addition of various pistol ports and vision ports. 145 were built and these were issued to panzer battalions and regiments plus armoured signal units. These vehicles saw action in the Balkans, Russia and North Africa.
