Year | February 1942 |
Vehicle Type | Light Flak Gun on Sd.Kfz 7 Half-Track |
Origin & Designer | Germany/Krauss-Maffei |
Numbers Produced | 1.137 |
Crew | 7 (Commander, 2 x Gunner, 3 x Loaders & Driver) |
Main Armament | 1 x 37mm L/57 FlaK 37 |
Main Armament | [@sponson_traverse] |
Elevation | -10° to +85° |
Turret Traverse | [@turret_traverse] |
Gun Traverse | 360° |
Gun Mount | [@gun_mounts] |
Maximum Range | [@maximum_range] |
Armour Penetration | [@armour_penetration] |
Gun Sight | Flakviser 40 |
Secondary Armament | 1 x 7.92mm MG34 (No Mount) |
Smoke Discharger | [@smoke_discharger] |
Ammunition Carried | 120 x 37mm & 600 x 7.92mm |
Height | 3.20m |
Width | 2.35m |
Length | 6.85m |
Combat Weight | 10.024 kg |
Ground Clearance | 0.40m |
Fording Depth | 0.65m |
Trench Crossing | 1.90m |
Obstacle Clearance | 0.31m |
Climbing Ability | 30° |
Radio | [@radio] |
Armour | Hull Front: 8mm Hull Sides: 8mm Hull Rear: 8mm Hull Top: 8mm Hull Bottom: None Gun Shield: 15mm
|
Engine | Maybach HL 62 (Petrol) |
Transmission | 4 Forward & 1 Reverse |
Maximum Road Range | 220 km |
Maximum Cross Country Range | 115 km |
Maximum Water Range | [@maximum_water_range] |
Maximum Road Speed | 44 kph |
Maximum Cross Country Speed | 21 kph |
Maximum Water Speed | [@maximum_water_speed] |
Variants | [@variants] |
Notes | Another version of the Sd.Kfz 7 was the 7/2. This was similar to the 7/1 except for the main armament with this version mounting a single 37mm FlaK 36. It had all the same features as the 7/1 and some were fitted with a similar armoured cab. It was issued to divisional anti-aircraft battalions and saw action on all fronts. |
