Year | November 1941 |
Weapon Type | Medium Anti-Tank Gun |
Origin & Designer | Germany/Rheinmetall |
Numbers Produced | 23.303 |
Crew | 8 (Commander, Range Finder, Gunner, Two Loaders & Three Ammunition Bearers) |
Calibre | 75mm (75x714R) |
Elevation | -5° to +22° |
Traverse | 65° |
Breech | Semi-Automatic Horizontal Sliding Block |
Recoil | Hydropneumatic |
Gun Sight | Z.F. 38 3x8 |
Gun Mount | [@gun_mounts] |
Carriage | Split Trail |
Trailers | [@trailers] |
Gun Shield | Two 4mm Plates (Spaced Armour) |
Armoured Plate | [@armoured_plate] |
Barrel Length | 3.450mm (L/48) |
Overall Length | 6.18m |
Width | 2.0m |
Height | 1.25m |
Weight | Weight in Traction: 1.500 kg Weight in Action: 1.425 kg |
Round Weight | Pzgr 40 – 9.55 kg (AP) Sprgr Patr 34 – 9.15 kg (HE) |
Muzzle Velocity | 990 m/s (AP) 548 m/s (HE) |
Feed | [@feed] |
Magazine Capacity | [@magazine_capacity] |
Practical Rate of Fire | [@practical_rate_of_fire] |
Rate of Fire | 14 r.p.m. |
Maximum Rate of Fire | [@maximum_rate_of_fire] |
Maximum Ceiling | [@maximum_ceiling] |
Maximum Ground Range | [@maximum_ground_range] |
Maximum Range | 10.000m |
Armour Penetration | 120mm @ 500m @ 30° |
Traction | Motorised (Opel Blitz 3-Ton Truck & Sd.Kfz 11) |
Variants | [@variants] |
Notes | The PaK 40 was a potent tank killer and was produced in large numbers. It was first issued in small numbers in early 1942 and was firmly established as the main anti-tank by 1943. It was very heavy compared to earlier models of anti-tank gun but its weight was over shadowed by its performance. |
