Year | 1943 |
Vehicle Type | Light Tank |
Origin & Designer | Sweden-Hungary/Landsverk-MAVAG, Ganz & Ruggyantagyar |
Numbers Produced | 80 (converted from Toldi II) |
Crew | 3 (Commander/Radio, Gunner & Driver) |
Main Armament | 1 x 40mm L/47 37/42M Gun |
Main Armament | [@sponson_traverse] |
Elevation | -10° to +25° |
Turret Traverse | 360° (Manual) |
Gun Traverse | [@gun_traverse] |
Gun Mount | [@gun_mounts] |
Maximum Range | [@maximum_range] |
Armour Penetration | [@armour_penetration] |
Gun Sight | Telescopic |
Secondary Armament | 1 x 8mm 34/40AM Machine Gun (Coaxial) |
Smoke Discharger | [@smoke_discharger] |
Ammunition Carried | 55 x 40mm & 3.200 x 8mm |
Height | 2.05m |
Width | 2.14m |
Length | 4.75m |
Combat Weight | 9.350 kg |
Ground Clearance | 0.35m |
Fording Depth | 0.70m |
Trench Crossing | 1.77m |
Obstacle Clearance | 0.60m |
Climbing Ability | 36° |
Radio | R/5a |
Armour | Hull Front: 23mm Hull Sides: 13mm Hull Rear: 10mm Hull Top: 10mm Hull Bottom: 6mm Gun Mantle: 33mm Turret Front: 33mm Turret Sides: 13mm Turret Rear: 6mm Turret Top: 6mm
|
Engine | Büssing NAG L8V/36TR (Petrol) |
Transmission | 3 Forward & 3 Reverse |
Maximum Road Range | 190 km |
Maximum Cross Country Range | [@maximum_cross_country_range] |
Maximum Water Range | [@maximum_water_range] |
Maximum Road Speed | 48 kph |
Maximum Cross Country Speed | [@maximum_cross_country_speed] |
Maximum Water Speed | [@maximum_water_speed] |
Variants | [@variants] |
Notes | It was during the Russian campaign that the need to up-grade the Toldi became apparent. The Toldi IIa had better armour and a more powerful 40mm gun. This increased the vehicles weight which had an effect on the speed and range. The Toldi IIa was still inferior to most Soviet tanks but was still kept in service until 1945. |
