Year | 1941 |
Vehicle Type | Medium Tank |
Origin & Designer | Italy/Ansaldo |
Numbers Produced | 752 |
Crew | 4 (Commander/Gunner, Loader, M.G. Gunner & Driver) |
Main Armament | 1 x 47mm L/32 Ansaldo M37 Gun |
Main Armament | [@sponson_traverse] |
Elevation | -10° to +12° |
Turret Traverse | 360° (Manual) |
Gun Traverse | [@gun_traverse] |
Gun Mount | [@gun_mounts] |
Maximum Range | [@maximum_range] |
Armour Penetration | [@armour_penetration] |
Gun Sight | [@gun_sight] |
Secondary Armament | Coaxial: 1 x 8mm Breda M38 Machine Gun Bow: 2 x 8mm Breda M38 Machine Guns AA Mount: 1 x 8mm Breda M38 Machine Gun |
Smoke Discharger | [@smoke_discharger] |
Ammunition Carried | 104 x 47mm & 2.832 x 8mm |
Height | 2.38m |
Width | 2.21m |
Length | 4.94m |
Combat Weight | 15.510 kg |
Ground Clearance | 0.41m |
Fording Depth | 1.0m |
Trench Crossing | 2.10m |
Obstacle Clearance | 0.80m |
Climbing Ability | 40° |
Radio | RF.1 CA |
Armour | Hull Front: 30mm Hull Sides: 25mm Hull Rear: 25mm Hull Top: 14mm Hull Bottom: 6mm Gun Mantle: 37mm Turret Front: 37mm Turret Sides: 25mm Turret Rear: 25mm Turret Top: 14mm |
Engine | SPA-15T M41 (Diesel) |
Transmission | 4 Forward & 1 Reverse |
Maximum Road Range | 220 km |
Maximum Cross Country Range | 140 km |
Maximum Water Range | [@maximum_water_range] |
Maximum Road Speed | 40 kph |
Maximum Cross Country Speed | 17 kph |
Maximum Water Speed | [@maximum_water_speed] |
Variants | [@variants] |
Notes | The M14/41 was basically an improved version of the M13/40. It had a better engine and improved armour but suffered from the same faults as its predecessor, and many broke down due to engine problems and had a tendency to catch fire when hit. It was just as cramped as the M13/40 and had the same main gun. Like the M13/40 many were knocked out in battle or captured. |
