Year | January 1943 |
Vehicle Type | Medium Tank |
Origin & Designer | Italy/Ansaldo |
Numbers Produced | 118 |
Crew | 4 (Commander/Gunner, Loader, M.G. Gunner & Driver) |
Main Armament | 1 x 47mm L/40 Ansaldo M39 Gun |
Main Armament | [@sponson_traverse] |
Elevation | -10° to +20° |
Turret Traverse | 360° (Powered) |
Gun Traverse | [@gun_traverse] |
Gun Mount | [@gun_mounts] |
Maximum Range | [@maximum_range] |
Armour Penetration | [@armour_penetration] |
Gun Sight | [@gun_sight] |
Secondary Armament | Coaxial: 1 x 8mm Breda M38 Machine Gun Bow: 2 x 8mm Breda M38 Machine Guns AA Mount: 1 x 8mm Breda M38 Machine Gun |
Smoke Discharger | [@smoke_discharger] |
Ammunition Carried | 111 x 47mm & 2.640 x 8mm |
Height | 2.39m |
Width | 2.23m |
Length | 5.04m |
Combat Weight | 15.500 kg |
Ground Clearance | 0.41m |
Fording Depth | 1.0m |
Trench Crossing | 2.10m |
Obstacle Clearance | 0.80m |
Climbing Ability | 40° |
Radio | RF.1 CA |
Armour | Hull Front: 42mm Hull Sides: 25mm Hull Rear: 25mm Hull Top: 14mm Hull Bottom: 6mm Gun Mantle: 37mm Turret Front: 49mm Turret Sides: 25mm Turret Rear: 25mm Turret Top: 14mm |
Engine | SPA 15TB M42 (Petrol) |
Transmission | 5 Forward & 1 Reverse |
Maximum Road Range | 220 km |
Maximum Cross Country Range | 140 km |
Maximum Water Range | [@maximum_water_range] |
Maximum Road Speed | 40 kph |
Maximum Cross Country Speed | 17 kph |
Maximum Water Speed | [@maximum_water_speed] |
Variants | [@variants] |
Notes | By 1942 the Italian army had come to realise that they needed a modern medium tank and this would take time to design, so they hastily adapted the M14/41 to act as an interim vehicle and this became the M15/42. It had a longer version of the 47mm gun, which could fire a variety of ammunition, including hollow charge rounds and a new petrol engine. It came too late to serve in North Africa and was only built in small numbers. |
