MOSCHETTO AUTOMATICO MODELLO 38A

MOSCHETTO AUTOMATICO MODELLO 38A
Image: MAB 38 (The Brigade)
Year1938
Weapon TypeSub-Machine Gun
Origin & DesignerItaly/Beretta
Numbers Produced[@numbers_produced]
Crew[@crew]
Calibre9mm (9x19)
Elevation[@elevation]
Traverse[@gun_traverse]
Cartridge Weight[@cartridge_weight]
Round Weight115gr (7.45g)
Barrel Length300mm
Overall Length947mm
Grenade Types[@grenade_types]
Mount[@mount]
Combat Weight5 kg
OperationBlowback
Cooling System[@cooling]
SightsFront Blade & Rear Flip
Feed10, 20, 30 or 40 Box Magazine
Practical Rate of Fire100 r.p.m.
Maximum Rate of Fire500 r.p.m.
Blank Cartridge[@blank_cartridge]
Muzzle Velocity429 m/s
Fuel Capacity[@fuel_capacity]
Minimum Range[@minimum_range]
Effective Range155m
Maximum Range220m
Armour Penetration[@armour_penetration]
Bayonet[@bayonet]
Traction[@traction]
Variants[@variants]
NotesThe Beretta Modello 38 was first issued to Italian police units stationed in Africa. The Italian army were impressed and decided to adopt a version to be used by elite troops and military police, but requested a modified variant which had no bayonet and a different recoil compensator. The MAB 38 was widely used and saw service on all fronts.
