Year | 1938 |
Vehicle Type | Light Tankette |
Origin & Designer | Japan/Hino Motors |
Numbers Produced | 616 (Both MG & Gun Models) |
Crew | 2 (Commander/Gunner & Driver) |
Main Armament | 1 x Type 97 7.7mm Machine Gun |
Main Armament | [@sponson_traverse] |
Elevation | [@elevation] |
Turret Traverse | 360° (Manual) |
Gun Traverse | [@gun_traverse] |
Gun Mount | [@gun_mounts] |
Maximum Range | [@maximum_range] |
Armour Penetration | [@armour_penetration] |
Gun Sight | [@gun_sight] |
Secondary Armament | [@secondary_armament] |
Smoke Discharger | [@smoke_discharger] |
Ammunition Carried | 2.800 x 7.7mm |
Height | 1.79m |
Width | 1.90m |
Length | 3.07m |
Combat Weight | 4.200 kg |
Ground Clearance | 0.29m |
Fording Depth | 0.76m |
Trench Crossing | 1.60m |
Obstacle Clearance | 0.81m |
Climbing Ability | 60° |
Radio | [@radio] |
Armour | Hull Front: 12mm Hull Sides: 7mm Hull Rear: 5mm Hull Top: 6mm Hull Bottom: 6mm Gun Mantle: 12mm Turret Front: 12mm Turret Sides: 7mm Turret Rear: 5mm Turret Top: 6mm |
Engine | Ikega 65 HP (Diesel) |
Transmission | 4 Forward & 1 Reverse |
Maximum Road Range | 241 km |
Maximum Cross Country Range | [@maximum_cross_country_range] |
Maximum Water Range | [@maximum_water_range] |
Maximum Road Speed | 40 kph |
Maximum Cross Country Speed | 25 kph |
Maximum Water Speed | [@maximum_water_speed] |
Variants | [@variants] |
Notes | The Te-Ke was a similar vehicle to Type 94 and had similar armour plus a two man crew. It came in two versions and the main difference was the armament, with one model armed with a single 7.7mm Type 97 machine gun and another with a 37mm gun. They were used as reconnaissance vehicles, but were thrown into action and used in armoured assaults. The Te-Ke was widely used and saw service on every front. |
