Year | 1936 |
Weapon Type | Light Anti-Tank Gun |
Origin & Designer | France-Romania/Schneider-Concordia |
Numbers Produced | 300 |
Crew | 6 |
Calibre | 47mm (47x343R) |
Elevation | -13° to +15° |
Traverse | 45° |
Breech | Vertical Sliding Wedge |
Recoil | Hydropneumatic |
Gun Sight | [@gun_sight] |
Gun Mount | [@gun_mounts] |
Carriage | Split Trail |
Trailers | [@trailers] |
Gun Shield | 7mm |
Armoured Plate | [@armoured_plate] |
Barrel Length | 2.497mm (L/44) |
Overall Length | 3.95m |
Width | 3.70m |
Height | 2.21m |
Weight | 628 kg (In Action) |
Round Weight | HE: 1.48 kg AP: 2.3 kg |
Muzzle Velocity | HE: 675 m/s AP: 750 m/s |
Feed | [@feed] |
Magazine Capacity | [@magazine_capacity] |
Practical Rate of Fire | [@practical_rate_of_fire] |
Rate of Fire | 18 r.p.m. |
Maximum Rate of Fire | [@maximum_rate_of_fire] |
Maximum Ceiling | [@maximum_ceiling] |
Maximum Ground Range | [@maximum_ground_range] |
Maximum Range | 6.700m |
Armour Penetration | 70mm @ 400m @ 30° |
Traction | Motorised (Malaxa UE Tractor) |
Variants | [@variants] |
Notes | The 47mm model 36 was designed by the French manufacturer Schneider and was initially designed for the French army, but lost out to Puteaux. The Romanian army bought 160 and later built another 140 under licence. It was built for motorised towing and pulled by the Malaxa UE tractor. |
