Year | July 1941 |
Vehicle Type | Light Tank |
Origin & Designer | [@designer] |
Numbers Produced | 4.200 |
Crew | 2 (Commander/Gunner & Driver) |
Main Armament | 1 x 20mm L/107 TNSh Cannon |
Main Armament | [@sponson_traverse] |
Elevation | -10° to +40° |
Turret Traverse | 360° (Manual) |
Gun Traverse | [@gun_traverse] |
Gun Mount | [@gun_mounts] |
Maximum Range | [@maximum_range] |
Armour Penetration | [@armour_penetration] |
Gun Sight | TMPD-1 |
Secondary Armament | 1 x 7.62mm DT Machine Gun (Coaxial) |
Smoke Discharger | [@smoke_discharger] |
Ammunition Carried | 780 x 20mm & 945 x 7.62mm |
Height | 1.80m |
Width | 2.30m |
Length | 4.10m |
Combat Weight | 5.800 kg |
Ground Clearance | 0.30m |
Fording Depth | 0.90m |
Trench Crossing | 1.70m |
Obstacle Clearance | 0.60m |
Climbing Ability | 30° |
Radio | 71-TK-3 |
Armour | Hull Front: 20mm Hull Sides: 15mm Hull Rear: 15mm Hull Top: 10mm Hull Bottom: 10mm Gun Mantle: 20mm Turret Front: 15mm Turret Sides: 15mm Turret Rear: 15mm Turret Top: 10mm |
Engine | GAZ-202 (Petrol) |
Transmission | 4 Forward & 1 Reverse |
Maximum Road Range | 600 km |
Maximum Cross Country Range | 300 km |
Maximum Water Range | [@maximum_water_range] |
Maximum Road Speed | 45 kph |
Maximum Cross Country Speed | 30 kph |
Maximum Water Speed | [@maximum_water_speed] |
Variants | [@variants] |
Notes | The T-60 was a light tank designed to be used in the reconnaissance role. It was a well-designed for a light tank and was armed with a 20mm canon and coaxial machine gun in a fully rotating turret. Its main draw backs were light armour and two man crew but despite its draw backs it served throughout the early phases of Barbarossa, until replaced by the improved T-70 and continued service on secondary fronts and in rear areas. |
