Year | September 1943 |
Vehicle Type | Heavy Tank |
Origin & Designer | [@designer] |
Numbers Produced | 130 |
Crew | 4 (Commander/Loader, Gunner, Hull Gunner/Mechanic & Driver) |
Main Armament | 1 x 85mm L/52 D-5T Gun |
Main Armament | [@sponson_traverse] |
Elevation | -5° to +24° |
Turret Traverse | 360° (Powered) |
Gun Traverse | [@gun_traverse] |
Gun Mount | [@gun_mounts] |
Maximum Range | [@maximum_range] |
Armour Penetration | [@armour_penetration] |
Gun Sight | PT4-13 |
Secondary Armament | 3 x 7.62mm DT Machine Guns (Coaxial, Bow & Turret Rear) |
Smoke Discharger | [@smoke_discharger] |
Ammunition Carried | 71 x 85mm & 2.150 x 7.62mm |
Height | 2.80m |
Width | 3.25m |
Length | 8.49m |
Combat Weight | 46.000 kg |
Ground Clearance | 0.40m |
Fording Depth | 1.60m |
Trench Crossing | 2.70m |
Obstacle Clearance | 1.20m |
Climbing Ability | 36° |
Radio | 71-TK-3 |
Armour | Hull Front: 75mm Hull Sides: 60mm Hull Rear: 70mm Hull Top: 30mm Hull Bottom: 40mm Gun Mantle: 95mm Turret Front: 100mm Turret Sides: 100mm Turret Rear: 100mm Turret Top: 40mm
|
Engine | V-2-K (Diesel) |
Transmission | 5 Forward & 1 Reverse |
Maximum Road Range | 251 km |
Maximum Cross Country Range | 150 km |
Maximum Water Range | [@maximum_water_range] |
Maximum Road Speed | 35 kph |
Maximum Cross Country Speed | 12 kph |
Maximum Water Speed | [@maximum_water_speed] |
Variants | [@variants] |
Notes | With the appearance of the new breed of German heavy tanks, it was apparent that new Soviet tank had to be developed to keep the balance. With the resulting IS tanks still in the early stages of development, the Soviets decided on an interim vehicle to in fill the void caused by the introduction of the Panther and the KV was chose as a basis for this vehicle. They used a KV-1 chassis and added a new turret in which to house the large 85mm gun. The resulting vehicle was soon arriving at the front and saw action at the back end of 1943. The KV-85 was a good heavy tank which had heavy armour and a powerful gun, it was only built in small numbers and these were thrown into action during the Soviet offensives in 1944. |
