Year | 1931 |
Weapon Type | Medium Anti-Aircraft Gun |
Origin & Designer | Germany-Russia/Rheinmetall-Factory No.9 |
Numbers Produced | 3.821 |
Crew | 7 |
Calibre | 76.2mm 76.2x558R) |
Elevation | -2° to +82° |
Traverse | 360° |
Breech | Vertical Wedge |
Recoil | Hydropneumatic |
Gun Sight | [@gun_sight] |
Gun Mount | Cruciform |
Carriage | Two Wheeled Axle |
Trailers | [@trailers] |
Gun Shield | [@gun_shield] |
Armoured Plate | [@armoured_plate] |
Barrel Length | 4.191mm (L/55) |
Overall Length | 6.70m |
Width | 5.26m |
Height | 5.30m |
Weight | Weight in Traction: 4.970 kg Weight in Action: 3.750 kg |
Round Weight | 6.5 kg |
Muzzle Velocity | 813 m/s |
Feed | [@feed] |
Magazine Capacity | [@magazine_capacity] |
Practical Rate of Fire | [@practical_rate_of_fire] |
Rate of Fire | 20 r.p.m. |
Maximum Rate of Fire | [@maximum_rate_of_fire] |
Maximum Ceiling | 9.250m |
Maximum Ground Range | 14.500m |
Maximum Range | [@maximum_range] |
Armour Penetration | 78mm @ 500m @ 30° |
Traction | Horse Drawn & Motorised |
Variants | [@variants] |
Notes | The 76mm 3-K was a Rheinmetall designed anti-aircraft gun and was built under licence in Russia. It was the first medium anti-aircraft gun used by the Soviet army and issued to heavy regiments with the national air defense force and to infantry divisions. |
