Year | August 1936 |
Weapon Type | Light Anti-Tank Gun |
Origin & Designer | Russia/Rheinmetall-Loginov |
Numbers Produced | 37.354 |
Crew | 5 |
Calibre | 45mm (45x310R) |
Elevation | -8° to +25° |
Traverse | 60° |
Breech | Vertical Sliding Wedge |
Recoil | Hydrospring |
Gun Sight | PP-1 M.38 |
Gun Mount | [@gun_mounts] |
Carriage | Split Trail |
Trailers | [@trailers] |
Gun Shield | 4.5mm |
Armoured Plate | [@armoured_plate] |
Barrel Length | 2.020mm (L/46) |
Overall Length | 4.26m |
Width | 1.37m |
Height | 1.25m |
Weight | Weight in Traction: 1.200 kg Weight in Action: 560 kg |
Round Weight | 1.43 kg (AP) |
Muzzle Velocity | 760 m/s |
Feed | [@feed] |
Magazine Capacity | [@magazine_capacity] |
Practical Rate of Fire | [@practical_rate_of_fire] |
Rate of Fire | 15-20 r.p.m. |
Maximum Rate of Fire | [@maximum_rate_of_fire] |
Maximum Ceiling | [@maximum_ceiling] |
Maximum Ground Range | [@maximum_ground_range] |
Maximum Range | 4.400m |
Armour Penetration | 43mm @ 90° @ 500m |
Traction | Horse Drawn & Motorized |
Variants | [@variants] |
Notes | The 45mm 53-K anti-tank gun was derived from the 37mm 1-K, and was rechambered to fire the larger round. It was an adequate weapon for the period and could knock out the early models of panzer, but once the Germans started to up-armour their tanks, the gun was found inadequate. It was issued to anti-tank units at battalion and divisional level, with others issued to independent anti-tank regiments. |
