Year | 1938 |
Weapon Type | Heavy Machine Gun |
Origin & Designer | Russia/Degtyaryov-Shpagin |
Numbers Produced | 9000 (1938-45) |
Crew | 5 |
Calibre | 12.7mm (12.7x108) |
Elevation | [@elevation] |
Traverse | [@gun_traverse] |
Cartridge Weight | [@cartridge_weight] |
Round Weight | 48.3gr (745g) |
Barrel Length | 1.070mm |
Overall Length | 1.625mm |
Grenade Types | [@grenade_types] |
Mount | Two Wheeled Carriage |
Combat Weight | 157 kg (With Mount) |
Operation | Gas Operated/Fully Automatic |
Cooling System | Air |
Sights | Front Post and Rear Tangent |
Feed | 50 Round Belt |
Practical Rate of Fire | 80 r.p.m. |
Maximum Rate of Fire | 550 r.p.m. |
Blank Cartridge | [@blank_cartridge] |
Muzzle Velocity | 850 m/s |
Fuel Capacity | [@fuel_capacity] |
Minimum Range | [@minimum_range] |
Effective Range | 2.700m |
Maximum Range | 7.850m |
Armour Penetration | [@armour_penetration] |
Bayonet | [@bayonet] |
Traction | [@traction] |
Variants | [@variants] |
Notes | The DShK (Degtyaryova-Shpagina Krupnokaliberny) was a heavy machine gun and was first developed in 1933. The early models were only built in small numbers and these were fed by a thirty round drum. Modifications were done to allow for a belt feed system and these were issued in 1938. It fired a heavy 12.7mm round and this allowed it to function as a ground weapon and as an anti-aircraft gun. In the ground role it was mounted on a wheeled carriage and provided with a gun shield. |
